The data acquisition system serves to monitor and record various instruments data required for monitoring various parameters.

Data loggers are at the centre of our rugged, reliable data acquisition systems. They are known for their flexibility, precision measurements, and dependability—even in harsh, remote environments. As for functionality, all of our data loggers:

Measure sensors Process data onboard Initiate measurement and control functions based on time or event Control external devices. PC support software to program the data logger Consume minimal power from a 12 Vdc source Interface with onsite and telemetry devices perform reliably under adverse conditions.

Advantages:
→ Accurate, robust, high resolution and good long term stability.
→ Capable of withstanding thermal shock without defeating performance.

Specification:
Main Module - CR-1000X or equivalent
Analogue Resolution - 0.33 microvolt to 333 micro volt
Input channels - 16 analogue channels and 08 differential channels
Memory - Operating system 2MB, SRAM 4MB
Input Power - 12V DC
Multiplexers - Any multiplexers for channel expansion
Operating Temperature - -25⁰C to 55⁰C
Interface - Supports interface for VW Sensors
Multiplexers - 16 channels for double ended and 32 channels for single ended
